Safety, Reliability & Convenience

• Integrated Traction and Steering Control: Combines traction and steering functionalities to reduce system failures and overall vehicle costs, while enhancing maintainability.

• Compact Design Without Compromising Standards: The controller is designed in accordance with the EN1175-2020 safety standard, supporting Performance Level D (PL=D) / Category 2 for driving functions and PL=D / Category 3 for steering functions.

• Comprehensive Protection Features: Equipped with overvoltage, undervoltage, overcurrent, and temperature protection mechanisms.

• Short-Circuit and Open-Circuit Protection: Low-power output ports are safeguarded against short circuits and open circuits.

• Durable Sealed Enclosure: Robust sealed housing and connectors meet the IP65 environmental sealing standard, ensuring suitability for harsh environments.

Flexibility

• IPM Motor Support: Compatible with Interior Permanent Magnet (IPM) motors, effectively enhancing system efficiency.

• Versatile I/O Interfaces:

• Supports up to 13 digital inputs.

• Accommodates 2 potentiometers.

• Provides 7 low-power outputs and 1 analog voltage output.

• Supports up to 4 quadrature encoder inputs.

• Offers 5V and 12V outputs with short-circuit protection.

• Multiple Communication Options: Facilitates CAN, serial, and Bluetooth debugging, delivering unparalleled flexibility.

• Encoder Compatibility: Supports sin/cos type encoders for traction motors.
